Model: IntelliBrite Architectural Series 12V Spa Light – White
Part Number/SKU: 618016
Application: Spa
Voltage: 12V (safety isolation transformer required, not included)
Wattage: 18W
Light Type: LED
Light Color: White LED; 100W incandescent equivalent
Cord Length: 50 ft
Face Ring: Stainless steel face ring (Pentair Architectural Series brochure, series-level)
Niche Type: Niche-mounted – Pentair spa niches only
Compatibility: Pentair niches only; Pentair automation systems, Color Sync Controller, Pentair Pool app

The Pentair IntelliBrite Architectural Series 618016 is the 12V, 18W white spa light from Pentair's Architectural Series, supplied with a 50-foot cord. It is the compact spa-size fixture for a Pentair spa (6-inch class) niche, and Pentair rates its output as equivalent to a 100W incandescent light. Pentair's cross-reference grid lists it as the Architectural Series replacement for the discontinued IntelliBrite 5G 640151, so it is the current part to specify when one of those lights needs replacing.

Output is white LED. Pentair states the Architectural Series white light is 80 percent more energy efficient than its previous generation while using 44 percent less power, and that its optics spread light widely and evenly in all directions to minimize hot spots, dark areas, glare and stripes. The series is certified to UL 676 and CSA C22.2 No. 89.

Installation is niche-mounted, and Pentair is explicit that the light must only be used in Pentair niches – installing it in another manufacturer's niche voids the UL approval and the warranty. Where local code requires a cord seal, Pentair specifies its plastic niches 79206600 / 79206700 with Cord Seal Kit 670044. As a 12-volt luminaire it must be powered through a safety isolation transformer, which is not included. Pentair lists the light as compatible with its automation systems and light controllers, the Color Sync Controller and the Pentair Pool app. Replacement parts published by Pentair for the spa light are Face Ring Kit 79111600, Lens Kit 602176, Gasket Kit 79108600z and Wire Clamp Kit 79210400.

Pentair's published warranty for IntelliBrite Architectural Series pool and spa lights is two years.

Key Features

• White LED spa light, 12V, 18W, 50 ft cord – 100W incandescent equivalent
• 80% more efficient than the previous generation, using 44% less power (Pentair)
• Wide, even light spread that minimizes hot spots, glare and stripes
• Certified to UL 676 and CSA C22.2 No. 89
• For Pentair niches only; requires a safety isolation transformer (not included)
• Works with Pentair automation systems, Color Sync Controller and the Pentair Pool app
• Pentair-listed replacement for IntelliBrite 5G 640151
• 2-year Pentair warranty

Specifications

What's Included

• IntelliBrite Architectural Series 12V white spa light with 50 ft cord
• Not included: niche, junction box, cord seal kit, safety isolation transformer, automation or controller equipment

The 618016 is the current Pentair part for a 12V white spa light in a Pentair niche with a 50-foot cord run, and the direct Architectural Series successor to IntelliBrite 5G 640151.
