Model: WaterColors Nicheless LED Light with HydroCool, Daylight White, 6W, 100 ft
Part Number/SKU: JLUW6W100
Application: Pool & Spa – also wet areas within 10 ft (6W)
Voltage: 12V AC (12–14 VAC Class 2 magnetic transformer required, not included)
Wattage: 6W
Light Type: LED
Light Color: Daylight White (5000K), 403 lumens
Cord Length: 100 ft
Face Ring: Black body; white and gray cosmetic trim rings included
Niche Type: Nicheless – standard 1-1/2 in plastic wall/return fitting (not included); minimum 7 in pipe
Compatibility: 1-1/2 in return fitting; AquaLink relay

The Jandy JLUW6W100 is a 6W, 12-volt Daylight White nicheless LED light from Jandy's WaterColors nicheless line with HydroCool technology, supplied with a 100-foot cord. Nicheless means it threads into a standard 1-1/2 inch plastic wall or return fitting (not included) with the included installation tool – no light niche, and because the light is 100 percent non-metallic no bonding is required. Jandy's manual calls for a minimum 7 in of 1-1/2 inch pipe through the wall for the 6W light, and the fixture is only 4-1/2 in long. Jandy allows only the 6 W models for wet-area lighting within 10 feet of a pool or spa, which makes this the light for steps, tanning ledges, spas and small water features.

It is a white-only light – not color-changing – rated by Jandy's cut sheet at 403 lumens at 5000K. Jandy's manual notes that only its color lights are non-dimmable; the white nicheless lights are described as dimmable-capable, but confirm dimmer relay compatibility with Jandy before specifying a dimming circuit. HydroCool uses the surrounding water to keep the LED running cooler for longer life, and Jandy states the lights use up to 87 percent less energy than incandescent pool lights.

Power is 12 VAC from a separate NRTL-listed Class 2 magnetic pool transformer (12–14 VAC), not included; Jandy's manual gives operating voltage ranges at the light by cord length and cautions not to exceed the transformer's load rating. Any Jandy AquaLink auxiliary relay can switch the transformer to control the light. The carton includes white and gray cosmetic trim rings; Jandy's quarter-moon and half-moon lens covers, which redirect light away from the eyes on steps, are available as lens cover kits in white, gray and black. Jandy's warranty document covers nicheless underwater lights for three years.

Key Features

• 6W Daylight White nicheless LED, 12V, 100 ft cord, 5000K, 403 lumens
• White-only light, not color-changing
• Only wattage Jandy approves within 10 ft of a pool or spa for wet-area lighting
• Threads into a standard 1-1/2 in return fitting – no niche, no bonding (min. 7 in pipe)
• HydroCool technology for cooler running and longer life; up to 87% energy savings (Jandy)
• Compact 4-1/2 in fixture; white and gray trim rings included
• Requires a separate 12–14 VAC Class 2 magnetic transformer; switchable from any AquaLink relay
• 3-year Jandy warranty (nicheless lights)

Specifications

What's Included

• Jandy nicheless LED light with 100 ft cord
• Protective cover, white and gray cosmetic trim rings, installation tool, guide (per Jandy manual)
• Not included: 1-1/2 in wall fitting, 12V transformer, junction box, automation

The JLUW6W100 is the nicheless 6W choice for steps, ledges, spas and wet areas on a 12-volt transformer circuit, with a 100-foot cord back to the junction box.
